Orange Pi PC Details
The Orange Pi PC is a compact, open-source single-board computer powered by an Allwinner H3 Quad-core Cortex-A7 processor. It features 1GB of LPDDR3 RAM and supports operating systems like Android 4.4, Ubuntu, and Debian.
Hardware Specifications
| CPU | H3 Quad-core Cortex-A7 H.265/HEVC 4K |
| GPU |
• Mali400MP2 GPU @600MHz • Supports OpenGL ES 2.0 |
| Memory (SDRAM) | 1GB DDR3 (shared with GPU) |
| Onboard Storage | TF card (Max. 32GB) |
| Onboard Network | 10/100M Ethernet RJ45 |
| Video Input |
• A CSI input connector Camera: • Supports 8-bit YUV422 CMOS sensor interface • Supports CCIR656 protocol for NTSC and PAL • Supports SM pixel camera sensor • Supports video capture solution up to 1080p@30fps |
| Audio Input | MIC |
| Video Outputs |
• Supports HDMI output with HDCP • Supports HDMI CEC • Supports HDMI 30 function • Integrated CVBS • Supports simultaneous output of HDMI and CVBS |
| Audio Output | 3.5 mm Jack and HDMI |
| Power Source | DC input can supply power, but USB OTG input doesn’t supply power |
| USB 2.0 Ports | Three USB 2.0 HOST, one USB 2.0 OTG |
| Buttons | Power Button(SW4) |
| Low-level peripherals | 40 Pins Header |
| GPIO(1x3) pin | UART, Ground. |
| LED | Power led & Status led |
| Key | IR input, Power |
| Supported OS | Android Ubuntu, Debian Image |
Pin Out Diagram
F-Tech Wiring Diagram (Without Relay)
Wiring Note:
- Coin Pin → Pin3 (PA12)
- SET PIN → Pin5 (PA11)
- CS GND → Pin6 (GND)
List Of Devices:
- Orange Pi One
- Orange Pi Usb Cable
- Atleast 16gb Class 10 SD Card
- Universal Coinslot
- 12v 5Amp Power Supply
- 12v DC Buck Converter
F-Tech Wiring Diagram (With Relay and LED Lights)
Wiring Note:
- Coin Pin → Pin3 (PA12)
- RELAY VCC PIN → Pin4 (5V)
- RELAY IN PIN → Pin5 (PA11)
- RELAY GND PIN → Pin6 (GND)
- Coinslot GND → Pin6 (GND)
List Of Devices:
- Orange Pi PC
- Orange Pi Usb Cable
- Atleast 16gb Class 10 SD Card
- Universal Coinslot
- 12v 5Amp Power Supply
- 12v DC Buck Converter
- 5v Single Channel Relay Module
- 12v LED Light
